OP TUBOMATIC V150 ES
The volume crimper Tubomatic V150 ES is ideal for crimping hydraulic hoses up to 2″1/2 six spirals and industrial hoses up to 4″ (with special dies). MAIN FEATURES…
TUBOMATIC-V150-ES overview
The volume crimper Tubomatic V150 ES is ideal for crimping hydraulic hoses up to 2"1/2 six spirals and industrial hoses up to 4" (with special dies). MAIN FEATURES : - ES4 Siemens PLC control with 7'' colour touch-screen display; - self lubricating moving components; - silent pump; - particularly narrow crimping head to crimp hose ends with large flanges or 90° fittings; - back limit switch; - protractor for fittings orientation; - hydraulic power pack included. Product specifications could be modified without prior notice.
MultiFlow is an authorized distributor of OP SRL products in the UAE, GCC and India. Use Add to Enquiry above for availability and a quotation.
Specifications
| CRIMPING FORCE | 300 TON (340 US TONS) |
|---|---|
| 6 SPIRALS 2 PIECES | 2'' 1/2 |
| INDUSTRIAL HOSE | 4'' |
| MAXIMUM DIAMETER | 118 mm (4.6'') |
| CRIMPING/HOUR | 1365 |
| CLOSING SPEED | 12mm/sec (0.4''/sec) |
| CRIMPING SPEED | 2,2 mm/sec (0.08"/sec) |
| OPENING SPEED | 35 mm/sec (1.3''/sec) |
| DIE OPENING | Ø + 70 mm (Ø + 2.7'') |
| OPENING WITHOUT DIES | 186 mm (7.3'') |
| STANDARD VOLTAGE | 375V-420V 50HZ 3PH |
| MOTOR POWER | 5,5 Kw (7.5 Hp) A=10,74 (A=20.20) |
| DIMENSIONS LxWxH | 1155x655x1640 mm (45.5”x25.8”x64.6”) |
| WEIGHT WITHOUT OIL | 1205 Kg (2657 Lbs) |
| OIL (NOT INCLUDED) | 167 Lt. (44 US Gal) |
| HYDRAULIC POWER UNIT DIMENSIONS L x W x H | 835x950x1075mm (32.9"x37.4"x42.3") |
| HYDRAULIC POWER UNIT WEIGHT | 290 Kg (636 Lbs) |
| MAINTENANCE COUNTER FOR PERIODIC SERVICE NOTIFICATION | incl. |
| ELECTRONIC TOUCH SCREEN CONTROL | incl. |
| HYDRAULIC POWER UNIT SEPARATE FROM THE MACHINE | incl. |
| CRIMPING THROUGH PRESSURE CONTROL | incl. |
| ELECTRIC PEDAL | incl. |
| GONIOMETER FOR FITTINGS ORIENTATION | incl. |
| BARCODE READER | OPTIONAL |
| BACK LIMIT SWITCH | OPTIONAL |
| SPECIAL DIES | OPTIONAL |
| MIRROR | OPTIONAL |
| CRIMPING SPEED CONTROL SYSTEM | OPTIONAL |
| SPECIAL VOLTAGE | OPTIONAL |
| CAMERA | OPTIONAL |
| DISPENSER + QUICK CHANGE TOOL | OPTIONAL |
| MARKING DIES | OPTIONAL |
| MULTISTEP CRIMPING DIAMETERS | OPTIONAL |
| FRONT AND REAR PROTECTION NET WITH ACTIVATION LIMIT SWITCH | OPTIONAL |
Videos
Downloads
Manufacturer reference: https://op-srl.it/en/products/tubomatic-v150-es
