OP TUBOMATIC H47 PM
The crimper Tubomatic H47 PM is ideal for crimping hydraulic hoses up to 1″ 2 braids. This versatile machine can be used for several applications and it is…
TUBOMATIC-H47-PM overview
The crimper Tubomatic H47 PM is ideal for crimping hydraulic hoses up to 1" 2 braids. This versatile machine can be used for several applications and it is perfect for outdoor service interventions. MAIN FEATURES : - manual pump; - equipped with an electric limit switch, indicating when the crimping diameter is reached; - tool for dies change. Product specifications could be modified without prior notice.
MultiFlow is an authorized distributor of OP SRL products in the UAE, GCC and India. Use Add to Enquiry above for availability and a quotation.
Specifications
| CRIMPING FORCE | 100 TON (110 US TONS) |
|---|---|
| CAPACITY | 1'' 2 SP |
| MAXIMUM DIAMETER | 46 mm (1.8") |
| DIE OPENING | Ø + 20 mm (Ø + 0.7'') |
| 90° FITTINGS | 3/8'' |
| DIMENSIONS L x W x H | 390x510x300 mm (15.3''x20''x11.8'') |
| WEIGHT | 32 KG (71 Lbs) |
| OIL (INCLUDED) | 0,75 LT. incluso |
| REQUIRED EFFORT ON THE LEVER | 30 KG (66 Lbs) |
| SINGLE-ACTING CYLINDER | incl. |
| DIES-STORAGE DRAWER | incl. |
| DIES CHANGE TOOL | OPTIONAL |
| SPECIAL DIES | OPTIONAL |
| STORAGE CASE+ 8 DIES + DIES CHANGE TOOL | OPTIONAL |
