OP AV03 EL
Roll over image to zoom in
Hose winder AV03EL , with its max. loading capacity of 1.000 KG and a hose support wheel Ø 2440 mm, is the perfect solution to wind/unwind big bore…
AV03-EL overview
Hose winder AV03EL , with its max. loading capacity of 1.000 KG and a hose support wheel Ø 2440 mm, is the perfect solution to wind/unwind big bore industrial hoses, up to 8’’. Its central supports (height 765 mm), around which the hose is winded, can be moved and adjusted from a min. diameter of 790 mm up to a max. diameter of 1233 mm. It is operated by means of a remote control, which allows the possibility to adjust the working speed.
MultiFlow is an authorized distributor of OP SRL products in the UAE, GCC and India. Use Add to Enquiry above for availability and a quotation.
Specifications
| MAXIMUM LOADING CAPACITY | 1000 KG (2205Lbs) |
|---|---|
| HOSE | 8'' |
| HOSE SUPPORT DIAMETER | 2440mm (96.1") |
| STANDARD VOLTAGE | 400V 50HZ 3PH |
| MOTOR POWER | 3 KW (4 HP) |
| SUPPORTS MOTOR POWER | 1,5 KW (2 HP) |
| ROTATION SPEED (RPM) | 1,5 ÷ 7,5 |
| WEIGHT WITHOUT OIL | 1188 KG (2619Lbs) |
| DIMENSIONS L x W x H | 2440 X 2440 X 1732mm (96.1"x96.1"x68.2") |
| MINIMUM HOSE SUPPORTS Ø | 790mm (31.1") |
| MAXIMUM HOSE SUPPORTS Ø | 1233mm (48.5") |
| HOSE SUPPORTS HEIGHT | 765mm (30.1") |
Videos
Downloads
Manufacturer reference: https://op-srl.it/en/products/av03-el
