NEM 6F300 – Flow Control Valve
Roll over image to zoom in
Flow Control Valve, NEM model 6F300 — Steel Body G3/8”-G1/2”.
NEM-6F300 overview
Flow Control Valve, NEM model 6F300 — Steel Body G3/8”-G1/2”.
MultiFlow is an authorized distributor of NEM Hydraulics products in the UAE, GCC and India. Use Add to Enquiry above for availability and a quotation.
Specifications
| Type | Flow Control Valve |
|---|---|
| Mounting | Steel Body G3/8”-G1/2” |
| Max regulated flow | 50 l/min A |
| Maximum flow | 90 l/min |
| Max pressure P:A | 350 bar |
| Seals | NBR |
| Weight | 1,8 Kg |
Downloads
Manufacturer reference: https://nem-hydraulics.com/dist/catalogs/catalog_partsInBody.pdf
